ELECTRIC VALVES

NORMALLY CLOSED

NORMALLY OPEN

Technical Specifications

TECHNICAL SPECIFICATIONS
Materials: cartridge in steel zinc plated, internal parts in hardened steel.
Flow range: 2 L/min;
Max. pressure: 250 bar (Coil 20 W)
Installation torque: see page 2
Cavity: 23081
Cartridge weight: see page 2
Coils: version C-13, see section Y
Oil temperature: -20°C + 80°C
Environment temperature: -30°C + 60°C
Ambient temperature range: nominal max. 10µ, ISO 4406-19/17/14 (NAS8) or less.
Inlet voltage fluctuations must not exceed ±10% of nominal voltage.

Download

COIL TO BE USED

BODY TO BE USED

CAVITY DIMENSIONS

Ask for further information

Other product wich could be interesting

2 way, pilot operated electric valve, double lock poppet, normally open

CAVITA'
SAE 08
SAE 10
SAE 12

PORTATA (l/min)
50 - 140

FP-22-PD-*-12-*-*

2 way, pilot operated electric valve, double lock poppet, normally open

2 way, pilot operated electric valve, normally open, bsp thread

CAVITA'
G 3/4"
G 1"

PORTATA (l/min)
70 - 150

FP-22-PD-*-12-*-*

2 way, pilot operated electric valve, normally open, bsp thread

2 way, pilot operated electric valve, normally open

CAVITA'
SAE 08
SAE 10
SAE 12
SAE 16

PORTATA (l/min)
50 - 150

FP-22-CP-*-15/16-*-*

2 way, pilot operated electric valve, normally open

2 way, pilot operated electric valve, normally open, bsp thread

CAVITA'
G 3/4"
G 1"

PORTATA (l/min)
70 - 150

FP-22-CP-*-15/16-*-*

2 way, pilot operated electric valve, normally open, bsp thread

2 way, pilot operated electric valve, normally open, bsp thread

CAVITA'
G 3/4"

PORTATA (l/min)
2-70

FP-22-CP-3/4-17-*-*

2 way, pilot operated electric valve, normally open, bsp thread
