ELECTRIC VALVES

NORMALLY CLOSED

NORMALLY OPEN

Technical Specifications

TECHNICAL SPECIFICATIONS
Materials: cartridge in steel zinc plated, internal parts in hardened steel.
Flow range: 2-70 L/min
Max. pressure: 350 bar
Installation torque: 45/55 Nm
Cavity: 21261
Cartridge weight: 0,25 Kg
Coils: version C-13, see section Y
Oil temperature: -20°C + 80°C
Ambient temperature range: -30°C + 60°C
Recommended filtration: nominal max. 10µ, ISO 4406-19/17/14 (NAS8) or less.
Inlet voltage fluctuations must not exceed ±10% of nominal voltage.

Download

COIL TO BE USED

CAVITY DIMENSIONS
