OVERCENTER

FULLY BALANCED

Type

FPOFB-25-C-*-*-*

Description

Fully balanced overcenter valve, cartridge version, SAE 08 cavity

Technical Specifications
  • TECHNICAL SPECIFICATIONS
  • Materials: body is steel made. Internal parts are in hardened steel. External surface: zinc plated.
  • Rated flow: 25 l/min
  • Max. setting: 350 bar
  • Adjustement means: leakproof screw adjustement
  • Adjustable pressure range: see pag.02
  • Cavity: 33082
Download
DATA SHEET
BODY TO BE USED
CAVITY DIMENSIONS
