OVERCENTER

NOT BALANCED

Type

FPO-300-C-35

Description

Overcenter valve, cartridge version, metric cavity

Technical Specifications
  • TECHNICAL SPECIFICATIONS
  • Materials: body is steel made. Internal parts are in hardened steel. External surface: zinc plated.
  • Rated flow: 300 l/min
  • Max. setting: 350 bar
  • Adjustement means: leakproof screw adjustement
  • Adjustable pressure range: see page 02
  • Cavity: 32421
Download
DATA SHEET
CAVITY DIMENSIONS

Ask for further information
