6 ways electric bankable flow diverters

ELECTRIC VALVES

DIVERTERS

Technical Specifications

TECHNICAL SPECIFICATIONS
Materials: cast-iron zinc plated body, internal parts in hardened steel.
Flow range: 80 l/min
Max. pressure:
internal drain 250 bar
external drain 310 bar
versions 6D-6E-6F 310 bar
Internal leakage with 100 bar max. 20 cc/min
Weight: see page 2
Coils: version C-25,4 see section Y
Oil temperature: -20°C + 80°C
Ambient temperature range: -30°C + 60°C
Recommended filtration: nominal max. 10µ, ISO 4406-19/17/14 (NAS8) or less.
Inlet voltage fluctuations must not exceed ±10% of nominal voltage.

Download

DATA SHEET

COIL TO BE USED

Ask for further information

Other product wich could be interesting

ATTACCHI
G 3/8"
G 1/2"

PORTATA (l/min)
50 - 60

FP-D1-3-E-G*-3*-*-*-*-*

3 ways flow electric diverters

ATTACCHI
G 3/8"
G 1/2"
J 3/8"

PORTATA (l/min)
50 - 60

FP-D1-6-E-G*-6*-*-*-*-*

6 ways flow electric diverters

ATTACCHI
G 1/2"

PORTATA (l/min)
80

FP-D2-6-E-G*-6*-*-*-*-*

6 ways flow electric diverters

ATTACCHI
G 1/4"

PORTATA (l/min)
25

FP-D3-6-E-G1/4-6*-*-*-A-*

6 ways flow electric diverters

ATTACCHI
G 3/8"
G 1/2"
J 3/8"

PORTATA (l/min)
50 - 60

FP-D3-6-E-G*-6*-*-*-*-*

6 ways flow electric diverters

ATTACCHI
G 3/8"
G 1/2"

PORTATA (l/min)
50 - 60

FP-D5-6-E-G*-6*-*-*-*-*-*

6 ways bankable flow electric diverters
