FLOW CONTROL VALVE

COMPENSATED

Type

FPVP-*-*-H-*

Description

In line three way pressure compensated flow regulator, with exceeding flow in pressure

Technical Specifications
  • TECHNICAL SPECIFICATIONS
  • Materials: aluminium body (std), steel body on request. Internal parts are in hardened steel.
  • Rated flow:
  • - 50 l/min with 30 l/min in “R” port for 3/8”
  • - 90 l/min with 50 l/min in “R” port for 1/2”
  • Max. pressure: 250 bar (std), 350 bar (S)
  • Standby pressure: about 5 bar
  • Weight: 1.300 Kg (std), 2.850 Kg (S)
