FLOW CONTROL VALVE

FOR HYDRAULIC MOTORS

Type

FPRF-90-DV-D2-R-1/2-*

Description

Three way, pressure compensated flow regulator, with exceeding flow to tank, flangeable on Danfoss motors “OMP/R/H” series

Technical Specifications
  • TECHNICAL SPECIFICATIONS
  • Materials: cartridges in steel zinc plated, internal parts in hardened steel. Body is in high strenght alluminium alloy.
  • Rated flow:
  • - 90 l/min with 60 l/min in “C2” port
  • Max. pressure: 250 bar (aluminium body)
  • Standby pressure: 10 bar
  • Weight: 1,600 Kg 1,600 Kg
Download
DATA SHEET
