HYDRAULICS EXCAVATOR VALVES

HYDRAULICS EXCAVATOR VALVES

Technical Specifications

TECHNICAL SPECIFICATIONS
Materials: body is in steel zinc plated. Internal parts are in hardened steel.
Rated flow: up to 500 l/min
Max. pressure: 420 bar
Adjustement means: leakproof screw adjustement
Adjustable pressure range: see page 02
Weight:: 15,300 Kg

Ask for further information

Other product wich could be interesting

Flow check and metering valve for booms, line mounted, right version

ATTACCHI
G 3/8"

PORTATA (l/min)
35

FPEXC-35-S-3/8-L-DX-05-50

Flow check and metering valve for booms, line mounted, right version

Flow check and metering valve for booms, line mounted, left version

ATTACCHI
G 3/8"

PORTATA (l/min)
35

FPEXC-35-S-3/8-L-SX-05-50

Flow check and metering valve for booms, line mounted, left version

Flow check and metering valve for booms, line mounted, right version

ATTACCHI
G 1/2"

PORTATA (l/min)
100

FPEXC-90-S-1/2-L-DX-05-50

Flow check and metering valve for booms, line mounted, right version

Flow check and metering valve for booms, line mounted, left version

ATTACCHI
G 1/2"

PORTATA (l/min)
100

FPEXC-90-S-1/2-L-SX-05-50

Flow check and metering valve for booms, line mounted, left version

Flow check and metering valve for booms, line mounted, right version

ATTACCHI
G 3/4"

PORTATA (l/min)
150

FPEXC-150-S-3/4-L-DX-05-50

Flow check and metering valve for booms, line mounted, right version

Flow check and metering valve for booms, line mounted, left version

ATTACCHI
G 3/4"

PORTATA (l/min)
150

FPEXC-150-S-3/4-L-SX-05-50

Flow check and metering valve for booms, line mounted, left version

Flow check and metering valve for booms, gasket mounted

ATTACCHI
G 3/4" SAE 3000
G 3/4" SAE 6000

PORTATA (l/min)
250

FPEXC-250-S-3/4-1F-SAE*-05-50

Flow check and metering valve for booms, gasket mounted

Flow check and metering valve for booms, gasket mounted

ATTACCHI
G 1" SAE 6000

PORTATA (l/min)
400

FPEXC-400-S-1-1F-SAE6000-05-50

Flow check and metering valve for booms, gasket mounted

Hammer control valves

ATTACCHI
G 3/4"

PORTATA (l/min)
200

FPEXCH-EV*-3/4-S-*

Hammer control valves
