OVERCENTER

FULLY BALANCED DUAL VALVE

Type

FPOFB-150-DD-3/4-L-35-*

Description

Fully balanced dual overcenter valve, line mounted

Technical Specifications
  • TECHNICAL SPECIFICATIONS
  • Materials: body is steel made zinc plated. Internal parts are in hardened steel.
  • Rated flow: up to 150 l/min
  • Max. setting: 350 bar
  • Pilot ratio: 1 : 4 (standard), 1 to 8 on request
  • Adjustement means: leakproof screw adjustement
  • Adjustable pressure range: see page 02
  • Weight: 6,500 Kg
Download
DATA SHEET
