OVERCENTER

SINGLE VALVE, LINE MOUNTED

DUAL VALVE, LINE MOUNTED

PARTIALLY BALANCED SINGLE VALVE

PARTIALLY BALANCED DUAL VALVE

FULLY BALANCED SINGLE VALVE

FULLY BALANCED DUAL VALVE

PARTIALLY BALANCED SINGLE VALVE

Technical Specifications

TECHNICAL SPECIFICATIONS
Materials: body is steel made zinc plated. Internal parts are in hardened steel.
Rated flow: up to 70 l/min
Max. setting: 350 bar
Pilot ratio: 1 : 4.25 (1 : 8 and 1: 11 on request)
Adjustement means: leakproof screw adjustement
Adjustable pressure range: see page 02

Download

Ask for further information

Other product wich could be interesting

Partially balanced single overcenter valve, line mounted

ATTACCHI
G 1/4"
G 3/8"
G 1/2"

PORTATA (l/min)
50

FPOB-*-S-*-L-*-*-*

Partially balanced single overcenter valve, line mounted

Partially balanced single overcenter valve, line mounted, internal pilot

ATTACCHI
G 1/4"
G 3/8"
G 1/2"

PORTATA (l/min)
50

FPOB-*-S-*-L-P-*-*-*

Partially balanced single overcenter valve, line mounted, internal pilot

Partially balanced single overcenter valve, line mounted, internal pilot, E series

ATTACCHI
G 1/2"

PORTATA (l/min)
70

FPOEB-70-S-1/2-L-P-A-*-*

Partially balanced single overcenter valve, line mounted, internal pilot, E series

Partially balanced single overcenter valve, line mounted, internal pilot

ATTACCHI
G 3/4"

PORTATA (l/min)
90

FPOB-90-S-3/4-L-P-35

Partially balanced single overcenter valve, line mounted, internal pilot

Partially balanced single overcenter valve, line mounted, internal pilot, E series

ATTACCHI
G 3/4"

PORTATA (l/min)
120

FPOEB-120-S-3/4-L-P-A-*-*

Partially balanced single overcenter valve, line mounted, internal pilot, E series

Partially balanced single overcenter valve, gasket mounted

ATTACCHI
G 1/4"
G 3/8"
G 1/2"

PORTATA (l/min)
50

FPOB-*-S-*-1F-*-*-*

Partially balanced single overcenter valve, gasket mounted

Partially balanced single overcenter valve, gasket mounted, SAE 6000

ATTACCHI
G 1/2"

PORTATA (l/min)
50

FPOB-50-S-1/2-1F-SAE-*-*-*

Partially balanced single overcenter valve, gasket mounted, SAE 6000

Partially balanced single overcenter valve, gasket mounted, C2 flanged, V1-C1 through ported, gauge port

ATTACCHI
G 1/4"
G 3/8"
G 1/2"

PORTATA (l/min)
50

FPOB-*-S-*-1F-P-M-*-*-*

Partially balanced single overcenter valve, gasket mounted, C2 flanged, V1-C1 through ported, gauge port

Partially balanced single overcenter valve, gasket mounted: C1-C2 flanged, pressure gauge port

ATTACCHI
G 1/4"
G 3/8"
G 1/2"

PORTATA (l/min)
50

FPOB-*-S-*-2F-P-M-*-*-*

Partially balanced single overcenter valve, gasket mounted: C1-C2 flanged, pressure gauge port
