PRESSURE RELIEF

PILOT OPERATED

Type

FPM-PEV-*-*-*-P-*-*

Description

Electric pilot operated relief valve

Technical Specifications
  • TECHNICAL SPECIFICATIONS
  • Materials: Body is in high strenght alluminium alloy, other external components are zinc plated steel. Internal parts in hardened steel.
  • Rated flow: 200 l/min
  • Max. setting: 400 bar
  • Adjustement means: leakproof screw
  • Coil voltage: 12/24 VDC
  • Weight (3/4”ports): 2,200 Kg
  • Weight (1”ports): 2,100 Kg
Download
DATA SHEET

Ask for further information
