PRESSURE RELIEF

SINGLE DIRECT ACTING

DUAL CROSS DIRECT ACTING

FOR HYDRAULIC MOTORS

SINGLE DIRECT ACTING

Technical Specifications

TECHNICAL SPECIFICATIONS
Materials: cartridge in steel zinc plated, internal parts are in hardened steel. Body (only CB version) is in high strenght alluminium alloy (steel body on request).
Rated flow: 80 l/min
Max. setting: 280 bar
Adjustement means: leakproof screw or handknob (P/R)
Installation torque: 70-75 Nm
Cavity: 22261
Cartridge weight: 0,355 Kg
Cartridge with body weight: 0,800 Kg (std) - 1.550 Kg (ver.S)

Download

CAVITY DIMENSIONS

Ask for further information
